JE 367900L Piston SUBARU FA20 ULTRA SERIES (Single Piece Set)
This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.
JE 367900L Piston SUBARU FA20 ULTRA SERIES (Single Piece Set)
ATOMIC-SHOP UA
вул. Набережно-Лугова, 29
Київ
02000
Ukraine
DESCRIPTION:
Piston Single, 2618, Inv Dome/Dish, 3.405 Bore, 1.290 CD, 0.866, Pin Dia, Set of 1.
More Information
Bore (in) 3.405
Bore (mm) 86.5
Top Compression Ring Thickness 0.0397
Second Compression Ring Thickness 0.0480
Oil Ring Thickness 0.111
Forging Type FSR
Volume (cc) -10.70
Series JE Pistons
Piston Head Type Inv Dome/Dish
Pin Diameter (IN) 0.866
Compression Height 1.290
Make TOYOTA
Wrist Pin Style - floating or press fit Floating
Wall Type CHAMFERED
Wall Thickness (IN) 0.230
Ringset Part Number JG1001-3405
Ring Brand ProSeal
Ringset Included Yes
Retainer Thickness 0.063
Retainer Lock Style Wire Lock
Retainer Lock Part Number 866-063-MW
Retainer Diameter (IN) 0.866
Replacement Single Piston 367900L
Piston Pin Inside Diameter 0.406
Piston Pin Material 9310 NICKEL CARBON STEEL ALLOY
Piston Material 2618
Piston Pin Length (IN) 2.250
Piston Avg Wt 324
Pin Offset Yes
Pin Brand JE Pistons
Pin Part Number 866-2250-23-93C
Pin Included Yes
Pin Diameter (mm) 22.00
Oil Rail Support Included No
Deck Clearance 0.000
Brand JE Pistons
