AKRAPOVIC L-HD12SO1 Optional Link Pipe (SS) for HARLEY-DAVIDSON Pan America 1250 2021-2023
This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.
AKRAPOVIC L-HD12SO1 Optional Link Pipe (SS) for HARLEY-DAVIDSON Pan America 1250 2021-2023
ATOMIC-SHOP UA
вул. Набережно-Лугова, 29
Київ
02000
Ukraine
This product was developed to be used with the Slip-On Line (Titanium) for the Harley-Davidson Pan America 1250 and is intended for use on racetracks and closed courses only. Fabricated from high-grade stainless steel, the fitting of the optional link pipe removes the stock pre-muffler, benefitting from a weight reduction of an impressive 76.5% (1.9 kg) over the stock version. When installed with the Slip-On Line (Titanium) exhaust, performance is increased by 2.7 kW (3.7 hp) at 9,000 rpm and torque is boosted by 6.8 Nm at 2,900 rpm when tested on the Akrapovic in-house dyno against a bike with a standard stock exhaust. It serves up a deep racing tone, perfectly in keeping with the V-twin engine. No remapping of the ECU is required during installation.
EC/ECE type approval of the Slip-On Line (Titanium) exhaust is not valid if the optional link pipe is attached.
The product is developed and tested on EU vehicle specification and does not fit on the non-EU spec models.
THIS PRODUCT DOES NOT MEET EMISSION COMPLIANCE REQUIREMENTS FOR STREET OR HIGHWAY USE.
- Power +2.7 kW at 9000 rpm
- Torque +6.8 Nm at 2900 rpm
- Weight -1.9 kg
VIEW THE DATA
| Unit | Stock | Akrapovic | Max gain | |
|---|---|---|---|---|
| Max. power | kW | 109.1 / 9200 rpm | 111.4 / 9100 rpm | + 2.7 / 9000 rpm |
| HP (m) | 148.3 / 9200 rpm | 151.4 / 9100 rpm | + 3.7 / 9000 rpm | |
| HP (i) | 146.3 / 9200 rpm | 149.4 / 9100 rpm | + 3.6 / 9000 rpm | |
| Max. torque | Nm | 122.2 / 8300 rpm | 124.5 / 8300 rpm | + 6.8 / 2900 rpm |
| lb-ft | 90.1 / 8300 rpm | 91.8 / 8300 rpm | + 5 / 2900 rpm | |
| Weight | kg | 2.51 | 0.59- 1.9 | - 1.9 |
| lb | 5.5 | 1.3- 4.2 | - 4.2 | |
| % | - 76.5 | |||
| Noise | dB | 91.3 / 3800 rpm | 98.6 / 3800 rpm | 7.3 |
| Inst. time | min | 60 |
